Only one model available at the price of £62,000 plus Vat.
Contact Us
Key Features
High-Performance Engine: Powered by a Yanmar 4-cylinder diesel engine (41 kW/55 HP) meeting Tier 4 Final/Stage V emissions standards, ensuring fuel efficiency and reduced environmental impact.
Reduced Tail Swing Design: Minimizes rear overhang (swing radius: 1,990 mm / 6.5 ft) for safe operation near obstacles and in urban environments.
Enhanced Hydraulic System: Features two-speed travel, auxiliary hydraulic circuits (standard and high-flow), and proportional controls for smooth, precise operation of attachments.
Impressive Digging Capabilities: Offers a max digging depth of 4.3 meters (14.1 ft) and bucket digging force of 56 kN, ideal for demanding excavation tasks.
Operator-Centric Cab: ROPS/FOPS-certified canopy with climate control, adjustable suspension seat, and intuitive joystick controls for all-day comfort.
Durable Construction: Reinforced undercarriage, heavy-duty boom/arm, and steel track guards for longevity in tough conditions.
Technical Specifications
Operating Weight: 8,000 kg (17,637 lbs)
Bucket Capacity: 0.28–0.38 m³ (0.37–0.5 yd³)
Engine: Yanmar 4TNV98, 3.3 L, turbocharged diesel
Fuel Capacity: 130 L (34.3 gallons)
Track Width: Adjustable (500/600/800 mm) for enhanced stability
Max Travel Speed: 5.5 km/h (3.4 mph)
Swing Speed: 9.5 rpm
Ground Clearance: 440 mm (17.3 in)
Operator Environment
Ergonomic Cab: Spacious, sound-dampened cabin with air conditioning, heated seat, and a 7-inch LCD touchscreen for monitoring machine performance.
360° Visibility: Large windows, LED work lights, and optional rearview camera system for improved safety in low-light conditions.
Advanced Controls: Electro-hydraulic joysticks with adjustable sensitivity and customizable settings for seamless operation.
Maintenance & Efficiency
Easy Service Access: Centralized grease points, swing-open engine hood, and tilting cooling system for simplified maintenance.
Eco Mode: Optimizes engine and hydraulic performance to reduce fuel consumption without sacrificing power.
Auto-Idle/Shutdown: Automatically reduces engine speed during inactivity and shuts down after preset intervals to conserve fuel.
Applications
Road construction and maintenance
Deep trenching and foundation work
Material handling and loading
Demolition and site clearing
Forestry and land development
Safety & Compliance
ROPS/FOPS-certified operator protection.
Automatic engine overspeed shutdown and emergency stop button.
Complies with global emissions regulations (Tier 4 Final/Stage V).
Attachments
Compatible with a wide range of tools for multifunctional use:
Hydraulic breakers, augers, and tilt rotators
Grapples, rakes, and compaction plates
Rock buckets, grading buckets, and ditch-cleaning buckets
